BES02K3
Typecode:
BES M12ML-PSC30A-S04G-W
Product description
BES inductive factor 1 sensors from Balluff can be used wherever different types of metals must be uniformly identified with high precision. An all-around reliable sensor for recognizing all metals, without a reduction factor at the switching distance: ferrous and non-ferrous metals, steel, brass, aluminum etc. Additionally, they are magnetic-field-resistant, making them useable in areas with a strong electromagnetic field – such as welding plants. We also offer variants with PTFE coatings for protection against welding spatter.
Dimension |
Ø 12 x 65 mm |
Style |
M12x1 |
Installation |
for flush mounting |
Range |
3 mm |
Switching output |
PNP normally open (NO) |
Switching frequency |
2000 Hz |
Housing material |
Brass, PTFE coated |
Material sensing surface |
LCP/PTFE |
Connection |
Connector, M12x1-Male, 4-pin |
Operating voltage Ub |
10...30 VDC |
Ambient temperature |
-25...70 °C |
Magnetic field immune |
magnetic field immune (AC/DC) |
IP rating |
IP67 |
Approval/Conformity |
CE, cULus, EAC, WEEE |
Additional features |
Factor 1, Weld immune |
