| Product characteristics |
| Number of inputs and outputs |
Number of analogue outputs: 1 |
| Measuring range [°C] |
-50...150 |
| Process connection |
threaded connection G 1/4 |
| Installation length EL [mm] |
25 |
| Application |
| Special feature |
Gold-plated contacts |
| Measuring element |
1 x Pt 1000; (to DIN EN 60751, class A) |
| Media |
liquids and gases |
| Pressure rating [bar] |
400 |
| Note on pressure rating |
| sensor |
| When mounted in adapters the specifications of the adapter data sheet apply. |
|
| Electrical data |
| Operating voltage [V] |
18...32 DC; ("supply class 2" to cULus) |
| Current consumption [mA] |
< 50 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time [s] |
1 |
| Inputs / outputs |
| Number of inputs and outputs |
Number of analogue outputs: 1 |
| Outputs |
| Total number of outputs |
1 |
| Output signal |
analogue signal; IO-Link; (configurable) |
| Number of analogue outputs |
1 |
| Analogue current output [mA] |
4...20 |
| Max. load [Ω] |
250; ((18...19 V); 19...32 V: 300 Ω) |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Measuring/setting range |
| Measuring range [°C] |
-50...150 |
| Factory setting |
-50...150 °C |
| Resolution |
| Resolution of analogue output [K] |
0.04 |
| Accuracy / deviations |
| Precision analogue output [K] |
± 0,3 + (± 0,1 % MS) |
| Temperature coefficient [% of the span / 10 K] |
0,1; (in case of deviation from the reference condition 25 ± 5 °C) |
| Response times |
| Dynamic response T05 / T09 [s] |
1 / 3 |
| Interfaces |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| Operating conditions |
| Ambient temperature [°C] |
-25...80 |
| Storage temperature [°C] |
-40...100 |
| Protection |
IP 67; IP 68; IP 69K |
| Tests / approvals |
| EMC |
|
| Shock resistance |
| DIN IEC 68-2-27 |
50 g (11 ms) |
|
| Vibration resistance |
| DIN IEC 68-2-6 |
20 g (10...2000 Hz) |
|
| MTTF [years] |
572 |
| UL approval |
|
| Mechanical data |
| Weight [g] |
84 |
| Dimensions [mm] |
Ø 18.7 |
| Materials |
stainless steel (1.4404 / 316L); PEI; FKM |
| Materials (wetted parts) |
stainless steel (1.4404 / 316L); O-ring: FKM |
| Tightening torque [Nm] |
35 |
| Process connection |
threaded connection G 1/4 |
| Probe diameter [mm] |
6 |
| Installation length EL [mm] |
25 |
| Displays / operating elements |
| Display |
| operating status |
1 x LED, green |
|
| Remarks |
| Remarks |
|
| Pack quantity |
1 pcs. |
| Electrical connection |
| Connection |
Connector: 1 x M12; coding: A; Contacts: gold-plated |
